Thermal Storage Electric Boiler
BZT-CN Series: Thermal Storage Heating & Hot Water System
Slash Your Operational Costs with Off-Peak Electricity & Advanced Thermal Storage
The Future of Smart, Cost-Effective Heating
Are volatile natural gas prices and high peak-time electricity rates eating into your budget? The Baozt BZT-CN Series is more than just a heating unit; it's a strategic energy asset. Engineered for a wide range of applications, from luxury homes to large commercial spaces, our system leverages cutting-edge solid-state thermal storage to decouple your heating from expensive energy hours. Store thermal energy when electricity is cheapest, and enjoy reliable, on-demand heating and hot water whenever you need it. Turn your energy bill from a liability into a competitive advantage.
The Conventional Heating Dilemma
- ✗ High & Volatile Costs: Unpredictable natural gas prices and expensive peak/flat-rate electricity.
- ✗ Environmental Pressure: Growing emissions regulations and carbon taxes for fossil fuel boilers.
- ✗ Inefficiency & Waste: Unable to leverage cheap off-peak electricity; slow response times and significant standby heat loss.
The Baozt Solution
- ✓ Predictable Low Costs: Capitalize on low, stable off-peak electricity rates for 100% of your heating needs.
- ✓ Eco-Friendly & Compliant: Zero on-site emissions or noise, easily meeting the strictest environmental standards.
- ✓ Maximum Efficiency: Over 95% thermal conversion efficiency with fully automatic, intelligent PLC control.
Advanced Solid-State Thermal Storage: The Core of Our Innovation
The heart of our system is a proprietary solid-state thermal storage core. This advanced composite material is heated during low-cost, off-peak hours, storing immense amounts of thermal energy. Unlike traditional water storage or phase-change materials, our solid-state core offers superior performance:
- High Thermal Density: Stores massive amounts of energy in a compact footprint, significantly reducing the space required compared to conventional boiler rooms.
- Extreme Stability & Safety: Operates at atmospheric pressure and is non-flammable, non-toxic, and non-corrosive, with a design life of over 20 years for ultimate long-term reliability.
- Superior Efficiency: Achieves over 95% heat storage and release efficiency, guaranteeing minimal energy loss from charge to discharge.
BZT-CN Series: Models & Technical Specifications
Choose from our range of standard models to perfectly match your building's heating area and hot water demands. Custom solutions are available for specialized requirements.
| Model | Power (kW) | Thermal Storage Capacity (kWh) | Reference Heating Area (m²) | Rated Water Output (t/h) | Outlet Temp. Range (°C) |
|---|---|---|---|---|---|
| BZT-CN50kw-0.8M-N | 50 | 350 | 50 | 0.8 | 30~95 |
| BZT-CN100kw-1.6M-N | 100 | 700 | 100 | 1.6 | 30~95 |
| BZT-CN150kw-2.4M-N | 150 | 1050 | 200 | 2.4 | 30~95 |
| BZT-CN200kw-3.2M-N | 200 | 1400 | 300 | 3.2 | 30~95 |
Note: Reference heating area is an estimate and may vary based on building insulation, climate zone, and desired temperature. All models operate on a 380V/3-Phase power supply.
Uncompromising Safety by Design
Your team's safety is our highest priority. The BZT-CN series is engineered with multiple layers of intrinsic protection, eliminating the common hazards of traditional boilers:
- Atmospheric Pressure Operation: The core thermal storage unit is not a pressurized vessel, completely eliminating the risk of a boiler explosion.
- Water & Electricity Separation: The heating elements are fully isolated from the water circuit, preventing any risk of electric shock.
- No Combustion, No Fuel: With a purely electric process, there is zero risk of fire, fuel leaks, or carbon monoxide poisoning.
- Exempt from Boiler Inspections: The system does not fall under most jurisdictions' definitions of a pressurized boiler, exempting it from mandatory annual inspections and specialized operator licensing.
- Intelligent PLC Control: A fully automated system monitors temperature, pressure, and flow with multi-level alarms and emergency shutdown protocols for complete peace of mind.
Visualize Your Total Cost of Ownership (TCO)
The true cost of heating goes far beyond the fuel bill. See a comprehensive cost comparison for generating 1,000 kWh of usable heat (prices are illustrative and vary by region):
| Cost Factor | Baozt Thermal Storage Boiler | Natural Gas Boiler | Standard Electric Boiler |
|---|---|---|---|
| Energy Cost / 1,000 kWh Heat | ~$84.00 (1,050 kWh @ $0.08 Off-Peak) | ~$90.00 (38 CCF @ $2.35/CCF) | ~$210.00 (1,050 kWh @ $0.20 Peak/Flat) |
| Certified Labor | Not Required | Required (High Cost) | Sometimes Required |
| Annual Inspection | Exempt | Mandatory (Cost & Downtime) | Mandatory |
| Maintenance | Minimal (No combustion parts) | High (Burners, fuel lines, vents) | Moderate (Heating elements, controls) |
| Emissions / Carbon Tax | Zero | Applicable & Increasing | Zero (On-site) |
| Est. Total Cost Advantage | SIGNIFICANT SAVINGS | HIGH | VERY HIGH |
This comparison highlights how the Baozt solution eliminates multiple hidden costs, leading to a drastically lower total cost of ownership and a rapid return on investment.
Your Path to Energy Independence
- Consultation & Analysis: We evaluate your heating demand, operational schedule, and local electricity tariffs to provide a detailed savings report.
- Custom System Proposal: We recommend the ideal BZT-CN model and provide a transparent proposal outlining the system cost and projected ROI.
- Professional Installation & Commissioning: Our certified team handles fast, minimally disruptive installation, connecting to your existing water and power infrastructure.
- Empowered Operation & Support: Enjoy full control of your new energy asset, backed by our expert support and available preventative maintenance plans to ensure decades of peak performance.
Frequently Asked Questions (FAQ)
Q: Is there enough stored heat to handle a sudden cold snap?
A: Absolutely. Our systems are sized with a significant safety margin to account for local climate extremes and demand fluctuations. The large thermal storage capacity is specifically designed to handle these events, automatically adjusting heat output to maintain a constant, comfortable indoor temperature without interruption.
Q: What are the site requirements for installation?
A: Significantly less than a traditional boiler room. You need a stable, level foundation capable of supporting the unit's weight, access to a 380V/3-Phase power supply, and connections for your heating circuit's supply/return lines. No dedicated boiler room, chimney, or fuel storage is required.
Q: What kind of maintenance is required?
A: The BZT-CN series is designed for maximum reliability and minimal maintenance. The key advantage is the absence of moving parts, burners, and fuel lines. Routine maintenance is simple and primarily involves checking the water circulation pump and system settings. We provide a comprehensive manual and offer optional preventative maintenance plans for total peace of mind.
Take the Next Step to Smarter Heating
Ready to unlock unprecedented savings and energy independence? Contact our experts today for a free, no-obligation cost analysis and a custom proposal for your facility.
